Microwave Oven Hood Combo Service Manual — LIT 4317216
Original 03/97
REMOVING THE LINE FUSE
Personal Injury Hazard
Disconnect from the electrical supply be-
fore servicing the unit. Failure to do so
could result in death or electrical shock.
WARNING
2. Remove the two screws from the top of the
cabinet for the vent grille and remove the
grille (see the illustration on page 2-3).
3. Remove the control panel from the micro-
wave oven (see page 2-6).
4. Without touching the metal ends, unsnap
the line fuse from its holder.
5. Install the new line fuse in the fuseholder
and then reassemble the microwave oven.
CONTROL PANEL
OPENING
LINE FUSE
FUSEHOLDER
BLACK POWER
CORD LEAD
1. Disconnect the electrical supply to the
microwave oven.
