Page 3-9
3-9
Microwave Oven Hood Combo Service Manual — LIT 4317216
Original 03/97
BLOWER MOTOR
FAN MOTOR
SYNCHRONOUS
MOTOR
Blower Motor
—Removes smoke and odors from the kitchen
cooking area through outside venting or recirculation.
Synchronous Motor
—Distributes microwave energy into the
oven during microwave cooking.
Fan Motor
—Cools the magnetron and circulates air through the
oven during microwave cooking.
MOTORS
