Microwave Oven Hood Combo Service Manual — LIT 4317216
Original 03/97
HIGH VOLTAGE
CAPACITOR
MOUNTING
STRAP
TAB &
SLOT
HIGH VOLTAGE
RECTIFIER
MOUNTING
FLANGE
RED WIRE
INSULATED
RED WIRE
WHITE WIRE
HV
CAPACITOR
SCREW
Removing The High Voltage Rectifier & Capacitor
