12
FREEZER LINER AND AIR FLOW PARTS
For Models: KSSC36FMS00
(Stainless Steel)
8198479
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2259385 Fan Motor
3 2169142 Fan Blade
4 2155590 Retainer,
Fan Motor
5 2155788 Gasket, Cover
6 2208968 Grommet
7 486194 Screw
8 2259464 Wedge, Air Duct
9 488500 Screw, Ground
10 2162085 Socket, Light (2)
11 488937 Clamp, Nylon
12 2255743 Light Bulb
14 2182119 Scroll, Fan
15 2259465 Wedge, Air Duct
16 2266801 Deflector, Air
17 2259018 Air Duct
19 Block, Fan Scroll
2209481 Right
2209066 Left
21 Liner (Not A
Serviceable Part)
22 2266805 Pad, Air Baffle
23 2259025 Cover, Air Outlet
24 2259367 Light Shield
25 2259067 Cover, Evaporator
26 488687 Screw
27 487539 Screw
29 2259054 Deflector, Air
Duct
30 1112260 Support,
Evaporator
31 2196483 Shelf, Stud (20)
32 8281158 Screw
33 Evaporator,
Cover Rail
2221107 Left Side
2259355 Right Side
34 2220904 Gasket (2)
Evaporator Cover
37 2187520 Harness, Evap Fan
38 2220241 Insulation (4)
39 2213442 Thermistor
40 2209204 Clip, Thermistor
41 1116793 Cover, Thermistor
42 2006475 Screw
43 2259057 Gasket, Air Duct
44 2257571 Bracket, Light
45 2259446 Spacer, Light
Bracket
46 2259032 Ladder, Shelf
47 2259397 Support, Screw
48 2259466 Gasket, Air Duct
49 2266949 Thermistor
55 2196155 Defrost, Bi−Metal
56 8281185 Screw
