KitchenAid KSSC36FMS00 - Page 20

LOWER UNIT AND TUBE PARTS
20
For Models: KSSC36FMS00
(Stainless Steel)
8198479
Illus. Part
No. No. DESCRIPTION
3 486194 Screw
4 2215508 Bracket
5 2259244 Side Support
6 2259303 Suction Tube
8 2259304 Tube, Connect
(Drier/Restrictor)
9 2259329 Heater, Drain Pan
10 2209450 Hanger, Heater
11 2005908 Shield, Drain Pan
13 2300191 Tube, Discharge
14 2216113 Thermistor
15 2257639 Clip, THermistor
16 2259029 Evaporator
17 2006749 Heater, Defrost
18 1113048 Clamp, Heater (2)
20 2220832 Gasket, Evaporator
21 857547 Wire Tie
22 2215691 Clip, Heat
Exchanger
25 2001264 Drain Pan
26 Bracket, Drain Pan
1113206 Left
1113207 Right
27 513942 Dampener
28 2215648 Damper, Heater
