KitchenAid KSSC36FMS00 - Page 22

ICEMAKER PARTS
22
PARTS NOT ILLUSTRATED
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
For Models: KSSC36FMS00
(Stainless Steel)
8198479
1 2300104 Cover, Bottom
Electrical
2 2259064 Cover, Fill Tube
Heater
3 2254792 Wire Assembly,
Icemaker
4 487539 Screw
5 628379 Clip, Fuse
6 2214613 Tube, Filter Inlet
7 2221140 Water Inlet
Tube Assembly
8 1106508 Seal Gasket
9 2254800 Tube, Filter
Outlet
10 2254709 Valve, Solenoid
11 489115 Fastener, Snap−In
12 2221070 Clamp, Tube
15 2208136 Clamp, Nylon
Valve
16 488937 Clamp Tube
17 2221240 Heater, Fill Tube
18 2221232 Cover
19 2221172 Shut Off Arm
20 628228 Mold & Heater
(Also Order
542638 Silicone
Grease)
21 627811 Motor
22 628356 Cup−Water Fill
23 627843 Ejector
24 2182124 Ice Striper
25 2195914 Support
26 627796 Retainer
Thermostat (2)
27 627985 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
29 2221231 Shield, Heat
30 489276 Screw
35 626653 Module Assembly
(Includes Items
21 & 41)
37 2004914 Water Valve
Mounting Bracket
41 489136 Screw (2)
43 486194 Screw
100 4317943 Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
2006783 Cleaner,
Stainless Steel
