KitchenAid KSSC42QTS02 - Control Panel Parts

7
CONTROL PANEL PARTS
For Model: KSSC42QTS02
(Stainless Steel)
W10175519
Illus. Part
No. No. DESCRIPTION
1 2316545 Control Box
2 2317000 Clip, Box
3 2310390 Wire, Jumper
4 2307592 Bracket,
Control Box
5 2307595 Shield,
Control Box
6 487539 Screw (2)
7 2306086 Display,
Ingredient Care
Center
8 2223857 Socket, Light
9 2326255 Light Bulb (2)
10 8281185 Screw
