COMPONENT ACCESS
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
n
4-1
Section 4:
Component Access
This secon provides service parts access, removal, and
installaon instrucons for the “KitchenAid Stainless Steel Tall
Tub Dishwasher.”
■ Insulaon Blanket
■ Door Latch Strike
■ Door Spring Adjustment
■ Water Inlet & Drain Hose
■ Overll Assembly
■ Accessing Door Components
■ Removing User Interface
■ Removing Latch Assembly
■ Removing Electronic Control Board
■ Removing Dispenser Assembly
■ Spray Arms, Feed Tube, and Manifold
■ Tub Components–Stainless Steel Models
■ Removing the Upper Rack(s)
■ Removing the Lower Spray Arm
■ Removing Filters
■ Removing ProScrub Manifold & Diverter Disk
■ Under the Tub Components
■ Heater
■ Removing Sump Assembly / Drain Pump
■ Removing Opcal Water Indicator
■ Removing Diverter Motor
■ Wash Motor
