UPPER RACK AND TRACK PARTS
11
For Models: KUDK03ITBL3, KUDK03ITWH3, KUDK03ITBT3, KUDK03ITBS3
(Black) (White) (Biscuit) (Stainless)
W10200482
Illus. Part
No. No. DESCRIPTION
1 8539235 Dishrack, Upper
2
W10078214 Mount, Wheel
Stationary
3 3385089 Track Rack
4
W10082860 Stop, Track
5 8539110 Handle, Dishrack
6
W10077844 Clip, No−Flip
7 9744566 Tine Row
8
W10082853 Clip, Pivot
9 8539102 Positioner, Dual
