PARTS AND FEATURES
Model KUDS01DJ
Front Control Panel
1
5
6
7
8
9
10
1
2
1
3
1
6
1
7
2
1
8
1
9
2
0
21
2
2
11
3
4
1
4
1
5
2
3
1.
Upper spray
2.
2-Position top rack adjuster [two]
3.
FLEXI-FOLD DOWN™ flexible tines
4.
SATINGLIDE™ upper rack track
5.
Model and serial number label
6.
Water inlet opening [in tub wall]
7.
FLEXI-FLIP-AWAY™ tines
8.
4-way HYDRO SWEEP™
spray arm
9.
Bottom rack
10.
Detergent dispenser
11.
Vent
12.
SURE-HOLD™ utility shelf [two]
13.
Top rack
14.
FLEXI-SPLIT™ divided tines
15.
SURE-HOLD™ light item clips
16.
Middle spray arm
17.
Silverware basket
18.
CULINARY CADDY™ utensil basket
19.
Overfill protection float
20.
Heating element
21.
SURE-HOLD™ mesh sack
22.
Rinse aid dispenser
23.
Control panel
/
