UPPER RACK AND TRACK PARTS
12
For Models: KUDS03FTBL3, KUDS03FTWH3, KUDS03FTBT3, KUDS03FTSS3
(Black) (White) (Biscuit) (Stainless)
W10202042
Illus. Part
No. No. DESCRIPTION
1 8539235 Dishrack, Upper
2
W10082839 Housing, Adjuster
3 Actuator, Adjuster
W10077838 Right Hand
W10077839 Left Hand
4 8268654 Adjuster Assembly
5 3385088 Wheel
6 8268703 Axel, Adjuster
7 8281156 Screw
8 9744566 Tine Row
9
W10082853 Clip, Pivot
10 8539102 Positioner, Dual
11
W10082840 Cover, Adjuster
12 9741232 Retainer
13
W10082834 Positioner, Arm
14
W10077844 Clip, No−Flip
15 3385089 Track, Assembly
16
W10082860 Stop, Track
17 8539110 Handle,
Dishrack
18
W10082649 Cupshelf
19
W10082848 Clip, Cupshelf
