10
TUB AND FRAME PARTS
For Models: KUDS24SEBL1, KUDS24SEWH1, KUDS24SEAL1
(Black) (White) (Almond)
4172113
Illus. Part
No. No. DESCRIPTION
1 9742605 Tub Assembly
3 9742612 Door Seal
4 9742788 Plug Tub (2)
5 9743468 Wheel & Mount
Assembly
(Also Order
Item 6)
6 9743002 Gasket, Bracket
Mounting
7 3378056 Tub Stiffener
8 3400003 Screw (8)
9 9743149 Rear Support
Assembly
10 343641 Screw
11 9742610 Connector
Tub To Brace
12 90767 Screw (2)
13 304392 Screw
14 3370389 Screw (2)
15 302819 Wheel Leg
16 3376439 Leveler, Leg
17 9743488 Spacer, Tank − RH
18 9743489 Spacer, Tank − LH
19 3370292 Terminal Box
20 3369138 Screw
21 300068 Cover, Terminal
Box
22 3371578 Screw
23 3371579 Nut
24 3370307 Strain, Relief
25 9743460 Trim Strip, Tub
26 304666 Retainer, Push (2)
27 9742789 Corner Trim, Tub
28 9742661 Shield, Sound
Tub
29 9742648 Bracket,
Thermostat
30 3371618 Thermostat
31 9742722 Strike, Latch
32 9743406 Pad, Friction
33 3370225 Screw, Ground
To Next Page
