17
Open the door and align top edges. Predrill 2 pilot holes using a
³⁄₃₂" drill bit. Use tape to mark the drill bit to gauge hole depth. Drill
pilot holes approximately 1¹⁄₂" (3.8 cm) into the top corners of the
door using hole in liner as a guide.
Install 2 long screws supplied in top corners to secure custom
wood panel in place.
Remove the short screws (3rd from top) on either side of the inner
door panel. Predrill 2 pilot holes using a ³⁄₃₂" drill bit. Use tape to
mark the drill bit to gauge the hole depth. Drill pilot holes
approximately 1¹⁄₂" (3.8 cm) using the door liner hole as a guide
into the panel. Install the 2 remaining long screws.
Choose Attachment Option
Use 2 or more people to move and install dishwasher.
IMPORTANT: The dishwasher must be secured to the cabinet.
There are two brackets found in the parts bag. Attach the
brackets using Option A if the countertop is wood, laminate or
another similar surface. If your countertop is marble, granite or
another hard surface, install using Option B.
Option A, Countertop attachment:
Remove the brackets from the package and insert into the open
slots on the left and right-hand top of the dishwasher collar as
shown.
Using a pair of pliers, bend the tab down to secure the bracket in
place. Repeat this step for the other side.
NOTE: Do not attach the dishwasher. This will be done later.
