Sauna
PAGE 7
50701162/12.12
8. Individual settings
I/O A D C B
Unit/button: Description:
A Cubicle light button
B Button Start
C LED SAUNA
D Temperature control knob
8.1. Temperature
Alter the temperature in the sauna using the temperature control knob D.
Normal temperature 85 °C - 95 °C.
The centre position of the temperature control corresponds to approx. 80 °C.
The temperature sensor is mounted in the warm air stream above the sauna heater.
There is an unavoidable difference between the temperature detected by sensor and
the temperature indicated. Therefore, the temperature control knob has no marked
scale.
Setting the temperature
1. Turn temperature control knob D clockwise as far as the stop.
2. Observe the temperature indicated in the cubicle.
3. Has desired temperature been reached? Slowly turn the temperature control knob D
anticlockwise.
A soft click in the control system can be heard. Leave the temperature control knob D in that
position.
After approx. 30 minutes: Climate in cabin is obtained.
Readjusting temperature
1. Readjust the temperature control knob D to the desired temperature.
2. Mark the temperature that you find the most comfortable.
8.2. Setting the exhaust air flap for cabin ventilation (option)
Correct ventilation is the prerequisite for a good climate.
Klafs exhaust wall with adjustable exhaust air flap (option) allows you to regulate the air flow and
volume.
Ventilation: Heating mode
Exhaust air flap, level 1.
With this position, there is only a low air flow.
Ventilation: Sauna mode
Exhaust air flap, level 4.
Bathing operation with maximum number of sauna
users. With this position, there is a maximum air
flow.
1
4
Level
It is better to obtain a larger air flow volume for the
sauna climate. Intermediate stages can be selected
in accordance with the number of sauna users.
