50
1. Connect the drain hose to the outlet pipe of indoor unit.
Step 7: connect wire of indoor unit
Step 6: install drain hose
outlet
pipe
drain hose
drain hose
tape
2. Bind the joint with tape.
• Add insulating pipe in the indoor drain
hose in order to prevent condensation.
• The plastic expansion particles are not
provided.
1. Open the panel, remove the screw on the
wiring cover and then take down the cover.
2. Make the power connection wire go through
the cable-cross hole at the back of indoor
unit and then pull it out from the front side..
power connection
wire
cable-cross
hole
