15
4
Align holes on blade to holes on
blade bracket, then tighten screws
with washer between blade and
screw. Make sure the arrow on blade
and blade bracket point towards the
same direction. Align the properly
fixed blade and blade bracket to the
holes on the fan body.
5
Install the glass shade on the light kit by pulling out one movable glass shade hook.
6
When mounting the fan, ensure that
the safety wire is looped across the
mounting bracket. Tighten the two
downrod set screws to make sure the
fan run stably. Then, install
downrod (ball part) into mounting
bracket opening that already securely
fastened to a structural ceiling
member. The tab opposite of the
mounting bracket opening should fit
in slot on ball.
