HANDLE INSTALLING AND DOOR REVERSING
Parts for door
reversing
1 Door hinge cover
2 ② Flange screw ②
3 Door hinge ②
4 Cap
5 Lower door hinge ②
6 Handle screw ②
7 Handle
Handle installation
Our beverage cooler is delivered with the
handle in a separate package.
1 Take out the handle; point it precisely to the
two holes on the left side of the door.
2 Push aside the door seal to reveal two holes;
insert the screws and screw the handle up.
Reversing the door
The appliance is delivered with the door
opening from left to right. To reverse the
opening direction:
1 Close the door.
2 Take off the door hinge cover (1) on the up
right corner; ②Unscrew the ange screws (2);
Take off door hinge (3); Remove the up left
side cap (4).
3 Lift the door up until the door gets off the lower
door hinge.
4 Unscrew the lower door hinge (5).
