25
EN
Remote control connection
green/yellow stripe
Light L
（blue）
Neutral N（White）
Ground
wire
N
L
L
Remote
control
receiver
input N
(Black)
(white)
Grey DC motor L
Pink DC motor L
Red DC motor L
Receiver place:
Canopy assembly
ok
Raise canopy to hanging bracket, aligning loosened screws in hanging bracket
with slotted holes in canopy. Twist canopy to lock. Re-insert screws and secured
all screws with screwdriver.
With hanging bracket secured to the outlet box and able to support to fan, you
are now ready to hang your fan. Grab the fan rmly with two hands. Slide
downrod through opening in hanging bracket and let hanging ball rest on the
hanging bracket. Turn the hanging ball slot until it lines up with the hanging
bracket tab.
Tip: Seek the help of another person to hold the stepladder in place and to lift
the fan up to you once you are set on the ladder.
