Important notes
• Leave at least 50 cm of space towards the ceiling so that you can install the unit
correctly.
• If you install the appliance above a washing machine, leave enough space under
the appliance to allow the air to circulate.
• Use a second person for installation.
Required tools for wall installation
• 3 mm drill (1x)
• Phillips screwdriver (1x)
• Wood screws Ø 12 mm (4x)
Supplied installation accessories for wall installation
Decription Figure Pc.
Retaining clamps
2
Spacers
2
Exhaust air connection
1
Screw 12 mm
4
Screw 25 mm
4
Wall installation
1
Find a suitable position on the wall and mark drill holes for the retaining clamps. Then
drill the holes.
