Bedienungsanleitung EK 22 Seite 18
___________________________________________________________________________
- In case of an error the light diode display also signals periodically at the end of an
pressing cycle. The signal indicates in this case the circuit opening by the electronic
fuse. A possible reason for that is that a pressing cycle was performed with an
incorrectly low battery. If the signal occurs even after changing the battery there must
be a different error or a service is due. In these cases the tool must be returned to the
manufacturer or an authorised service center.
- Is the unit in a state in which the diode should signal continuously (Battery empty) as
well as periodically (Service due) the diode signals first continuously and then
periodically.
5. Remarks in respect of the determined use
5.1. Operation of the units
First you have to select the right dies for the intended application.
Attention
Don’t use the tool without dies.
The crimping head has to be opened by unhooking the latch (Pos.-No. 3).
Afterwards the retaining clips (Pos.-No. 4) have to be pressed while the dies will be inserted
into the opened crimping head. After having completely closed the crimping head the trigger
lock (Pos.-No. 8) for the trigger (Pos.-No. 1) will be released, which means that it is pushed
down.
The crimping process will proceed as described in chapter 4.3. Please see also chapter 4.4. for
further information on the diode functions.
Attention
The crimping process can be interrupted at any moment by releasing the
trigger.
After the crimping process has been finished the trigger lock (Pos.-No. 8) has to be pushed up
again.
Attention
Before changing the dies the trigger has to be locked with the trigger lock
to avoid unintended use.
