Thanks for using Disco240 scanner console! Disco240 console has
internationally standard DMX512 signal output. Before operation,pl ease refer
to the user’s manual carefully.
1. Parameters
Output signal specifications DMX512 international standard
Total number of channels 192 channels
Number of scanners 24 scanner
Max. number of channels for the scanner 16
Number of chases(scenes) 12 chase
Maximal number of chase steps(scene) 40 steps
Total number of chase steps(scene) 480 steps
Scene pause time 0.1-25.5 second/step
Scene cross speed 0.1-25.5 seconds
Dimmer channel 24 channels
Display screen
LCD display, 16×2 characters
DMX512 outputs interface 3-core XLR pin socket and socket
Memory capacity 128 K high capacity memory card
Input voltage
50 / 60HZ—5V / 2000MA
Volume
483mm×178mm×80mm
80mm80mm
80mm
Weight 3.25Kg
