Klein Tools Hydra-Cool 2214 - Hydra-Cool Climber Pad Construction Details

3
FIGURE 1
A. Webbing and Velcro
®
construction
B. Warning Label
C. Klein Kord
®
climber retaining strap with Velcro
®
hook end
D. Catalog # and “L” for left leg shown on outside surface of pad
E. Tunnel slot for climber shank with sleeve
F. Slotted opening for climber sleeve loop
G. Velcro
®
loops – (soft side)
FIGURE 2
H. Free end of pad
I. Metal cinch loop
J. Cushioned leather-inside surface of the pad
K. Velcro
®
hooks – (sharp side)
FIGURE 3
L. Metal insert
M. Retaining bar
1. HYDRA-COOL™ CLIMBER PAD CONSTRUCTION DETAILS
E
B G
D
FIGURE 1 – Left Hydra-Cool™ Pad Construction Details (front)
CF
A
FIGURE 2 – Left Hydra-Cool™ Pad Construction Details (back)
K
H
I
FIGURE 3 – Left Metal Insert
L
M
Velcro
®
is a registered trademark of Velcro
®
Industries B.V.
