GENERAL SPECIFICATIONS - IR1
Klein Tools IR1 is an entry-level infrared thermometer with targeting
laser. It offers a wide measurement range, a 10:1 distance–to-spot
ratio, a targeting laser, and user-selectable from Fahrenheit to Celsius
temperature scales.
•
Environment: Indoor or outdoor
• Operating Altitude: 6562 ft. (2000 m)
•
Relative Humidity: <85% non-condensing
• Operating Temp:
32° to 122°F (0° to 50°C)
•
Storage Temp:
-4° to 140°F (-20° to 60°C)
•
Measurement Range: -4
° to 752°F (-20° to 400°C)
•
Units: Settable to °F or °C
•
Emissivity: 0.95 fixed
• Optical Resolution (Distance-to-spot): 10:1
•
Dimensions: 6" x 4.1" x 1.7" (152 x 104 x 43 mm)
• Weight:
7.4 oz. (210 g) including battery
•
Battery T
ype: 1 x 9V battery
•
Battery Life:
(Estimates assume 9V Zinc-Carbon Battery)
5 hours continuous use w/laser and backlight on.
•
Display: Backlit LCD with white backlight
• Display Resolution: 0.1°F (0.1° C)
•
Laser: FDA and IEC Class 2
• Wavelength:
630 – 670 nm
•
Max Power: 1mW
• Beam Divergence: 1.5mrad
• Standards: Certified to IEC EN 61326-1:2013, EN 61326-2-3:2013,
IEC EN 60825-1:2014
Complies with 21 CFR PAR
T 1040.10 and 1040.11
except for deviation pursuant to
Laser notice No.50,dated June 24, 2007
• Pollution degree: 2
•
Drop Protection: 6.6 ft. (2m)
Specifications subject to change.
ENGLISH
MEASUREMENT SPECIFICATIONS
• Response Time: <500ms
• Data hold: Yes
•
Spectral Response: 8000-14000nm
≥32
°F
(≥0
°C
) ±4
°F
(±2
°C
) or ±2%, whichever is greater
<32
°F
(<0
°C
)
±(4
°F
+ 0.1
°F
per degree below 32
°F
)
±(2.0
°C
+ 0.1
°C
per degree below 0
°C
)
• Repeatability: ±1.0% of reading or ±2°F(±1°C)
(whichever is greater).
• Temperature Correction Coefcient:
±0.1°F per °F (±0.1°C per °C), or ±0.2%
of reading (whichever is greater) when ambient temperature is above or
below 70 – 77°F (21 – 25°C).
Specifications subject to change.
