WIRING AND DISPLAY EXAMPLES
There is a break in the cable
continuity. A break in the shield or in the center wire can cause
an open fault. The cable does not pass and the ID remote
number on the other end of the cable cannot be determined.
The center wire of the cable is connected
to the shield, creating a short. The cable does not pass and the ID
remote number on the other end of the cable cannot be determined.
1. Remove single screw in the middle of the back of the VDV Scout™ Pro with a #1 Phillips head screwdriver.
Remove battery door.
2. Disconnect battery cable and recycle exhausted battery.
3. Acquire a 9 volt alkaline battery (IEC 6LR61, ANSI/NEDA 1640A).
4. Connect battery cable to new battery observing polarity and place into battery compartment.
5. Replace battery door and screw, taking care not to over-tighten it.
www.kleintools.com/warranty
Turn instrument off and disconnect any cables. Clean the instrument by using a damp cloth. Do not use abrasive cleaners or solvents.
Remove the batteries when instrument is not in use for a prolonged period of time. Do not expose to high temperatures or
humidity. After a period of storage in extreme conditions exceeding the limits mentioned in the Specifications section, allow the
instrument to return to normal operating conditions before using it.
This symbol indicates that equipment and its accessories shall be subject to a separate collection and correct disposal.
