TO PLAY WITH THE CALIBRATION, IF YOU DO NOT HAVE A REFERENCE COLORIMETER, THEN
YOU CAN
PRETEND THE FOLLOWING VALUES ARE "TRUE" VALUES FROM A REFERENCE COLORIMETER,
AND
PROCEED TO CALIBRATE THE K-10 TO MATCH THEM:
x y Y
white .280 .300 60
red .620 .320 2 (r,g,b Y cal taken from white))
green .280 .600 2
blue .140 .075 2
Store the cal file as "Trial Number 1" or something similar. Then whenever the colorimeter is run and
the"Trial Number 1"
file is chosen, and the same monitor is measured, the values for a white, red, green, blue field should
match
the entered values above, (except for the Y values of red, green, blue, which are taken as ratios of the
white value for cal purposes).
