4. GUARANTEE:
The electro technical part of the floor heating is guaranteed for 10 years. The thermostat
is guaranteed for 2 years. The guarantee does not apply to damage caused by external
factors and/or incorrect installation.
5. NECESSARY MATERIALS:
- Standard junction box (min 35mm deep, preferably 50mm) for the thermostat.
- Mounting material: Tie wraps, Spacerstrips or smooth Weld Mesh.
- Electrical conduit for the connecting cable for the thermostat.
- A multimeter to test the mat after each installation activity.
6. PREPARATIONS:
- Check that the cable length/wattage is correct for the area of free floor surface that
must be heated.
- Check the available electrical connection and mains voltage in the space for installation.
- Test the cable with a multimeter and check if the resistance (Ohms) coincide with the test
data in Section 2. Measure both between the resistance wires themselves and between
the resistance wire and the earth cladding, whereby the latter should give a reading of
0 and not swing.
- 1 or 2 grooves must be cut/ground in the wall for electrical conduits, 1 for the power
cable and 1 for the floor sensor. Do not run the power cable and sensor cable through
the same pipe.
TAKE CARE: DO NOT PLACE THE SENSOR IN THE VICINITY OF A (HIDDEN) RADIATOR
OR WATER PIPE!
- Ensure that the base floor is clean and level.
- Always apply insulation to the base floor if possible. Uninsulated floors will have
downward heatloss.
- Place expansion strips around the perimeter of the area (for coping with the contraction
and expansion of the floor).
5
