RW-10d/RW-12d
HIGH LEVEL
CONNECTIONS
FIGURE 4
Main speaker outputs on receiver
connected to high level inputs on
subwoofer amplifier (Right channel
is shown, repeat for Left)
RSW-10d LINE LEVEL
CONNECTIONS
FIGURE 5
[OR]
