General parameters
PARAMETER
DESCRIPTION
VALUE
Pr01
Ignition cycle maximum time
18’
Pr02
Flame stabilisation time during the “FIRE ON” phase
2’
Pr03
Time interval between two brazier cleaning operations
70’
Pr04
ON time of the screw feed motor reducer in the “LOAD PELL” phase
2,4”
Pr05
ON time of the screw feed motor reducer in the “FIRE ON” phase
2,8”
Pr06
ON time of the screw feed motor reducer in the “Po1” work phase
2,2”
Pr07
ON time of the screw feed motor reducer in the “Po2” work phase
3,5”
Pr08
ON time of the screw feed motor reducer in the “Po3” work phase
5,0”
Pr09
ON time of the screw feed motor reducer in the “Po4” work phase
6,3”
Pr10
ON time of the screw feed motor reducer in the “Po5” work phase
7,5”
Pr11
Alarm delay
30
Pr12
Temperature differential for switch-off/on
10°C
Pr13
Flue gas minimum temperature in order to consider the thermo stove on
43°C
Pr14
Flue gas maximum temperature accepted; if this occurs, the power is reduced to minimum and the flue gas
intake device speed is taken to the maximum value
260°C
Pr15
Minimum temperature to be reached for pump switch-on
50°C
Pr16
Flue gas intake speed in the “LOAD PELL” phase
12
Pr17
Flue gas intake speed in the “FIRE ON” phase
12
Pr18
Flue gas intake speed in the “Po1” work phase
06
Pr19
Flue gas intake speed in the “Po2” work phase
08
Pr20
Flue gas intake speed in the “Po3” work phase
10
Pr21
Flue gas intake speed in the “Po4” work phase
12
Pr22
Flue gas intake speed in the “Po5” work phase
15
Pr23
Time after which the thermo stove switches off if the boiler temperature is greater than that set in the “Set H2O”
120’
Pr24
Brazier cleaning duration
50”
Pr25
Differential on the H20 Set (boiler thermostat) for 3-way valve switch-over
10°C
Pr26
Differential on the Set Sani to switch-over the 3-way valve
5°C
Pr27
Switch-over delay
60”
Pr28
Flue gas temperature threshold for thermo stove switch-off
80°C
MAIN WORDING ON THE DISPLAY
DISPLAY
DESCRIPTION
Fun
ASP
IGNITION PHASE OF THE FLUE GAS INTAKE DEVICE
(duration about 10 seconds)
LoAd
PELL
PELLET LOADING AND FLAME IGNITION PHASE
(duration about 8-10 min)
FirE
ON
FLAME STABILISATION PHASE
(duration about 8-10 minutes)
Po1 , Po2 ,
61 °C
Po 1…Po 5= work power from 1 to 5.
Boiler water temperature in degrees centigrade
CooL
FirE
BRAZIER CLEANING CYCLE
Eco
H2o
ECONOMY FUNCTIONING
Temperature in boiler the same or greater than that set
via “SeT H2o”
StoP
FirE
FIRE OFF
This occurs with boiler temperature 10 °C over the
temperature set with SeT H2O or after 2 hours
functioning in economy. When the temperature in the
boiler lowers by at least 10 °C the thermo stove starts
automatically. It is also displayed when, the wood side
switches off with the “Pell on” function active.
Read the instruction manual for all of the other wording shown on the display.
DISPLAY
DESCRIPTION
Eco
toFF
ROOM THERMOSTAT CONTACT OPEN
Eco
Fumi
FLUE GAS TEMPERATURE TOO HIGH
The thermo stove automatically slows the power until the
flue gas temperature is lowered. Clean the internal “flue
gas pass” as soon as possible.
OFF
At te
STAND-BY
This occurs when attempts are made to re-ignite the
thermo stove before the flue gas intake device has finished
the switch-off cycle.
NO
FirE
NO FIRE
This occurs when for some anomaly the thermo stove
switches off without displaying alarms. It can also occur in
the switch-on phase if the pellet side does not ignite.
no
H2o
NO WATER
It occurs when the water inside the thermo stove is not at
correct level
Remove the upper majolica and the lid in order to verify
that the water inside the boiler body is at a level that it
covers the exchangers completely
