Make sure the machine is turned off and the power cable is disconnected. Unscrew the fixed M16 knob
（
C
）
and M12 knob (L), then lift the running board to close the machine, and lock the machine by M16
knob. Now you can move the machine for storage.
Lift up the running belt. Then put silicone oil (I) straightly at the back of the
running belt. Now start the machine and run for 3 minutes without any load on
the belt. We recommend that you oil the belt every 30 working hours.
(1) Running belt deviates to left - Start the machine, set speed at 2-3Km/h without a load on the belt,
use Allen key (J) to turn the screw 1/4 turn (see fig1). Then allow the machine to run without a load for 1-2
minutes. Repeat process until the belt becomes central.
(2) Running belt deviate to right - Start the machine, set speed at 2-3Km/h without a load on the belt,
use Allen key (J) to turn the screw 1/4 turn (see fig2). Then allow the machine to run without a load for 1-2
minutes. Repeat process until the belt becomes central.
Note: Do not exceed the maximum allowed running belt lateral positions mark on product while
adjusting so as to ensure the rear roller guard overlap the edges of the running belt by
minimum 10mm.
8. LUBRICATING THE BELT INSTRUCTIONS
9. RUNNING BELT ADJUSTMENT
