Set both sides of Fine Adjustment Pin to 0.
Disassembly is reverse order of SETUP 3~5.
Store Handle and Guide Bar in machine.
DISASSEMBLING AND STORAGE
*Lower Roller cannot be removed.
Tighten the Screw
Insert in gap
Insert into hole. See arrow.
Do not use
this hole
3. How to attach Upper Roller
1. Insert Upper Roller into left hole.
2. Insert the 2 U gaps of Roller Plate into pins.
3. Screw in the 2 Set Screws.
2. How to clean Upper Roller
1. Wash sufficiently with sponge soaked in dish soap. Rinse with warm water.
2. Wipe water off with dry cloth and leave to dry.
3. Use only dish soap to wash.
Remove Upper Roller while
lifting up Roller Plate.
Loosen
2 screws
● Remove Upper Roller to clean.
1. How to remove Upper Roller
1. Raise Roller Arm to highest position.
2. Loosen 2 screws on Upper Roller.
3. Remove Upper Roller while lifting up Roller Plate.
● Cleaning
1. Wipe with wet cloth and dish soap.
2. Rinse dish soap off with wet cloth.
3. Wipe water off with dry cloth and leave to dry.
MAINTENANCE
