KNOWINK Poll pad - Printer Setup and Connection

4
OPENING PROCEDURES | POLL PAD SETUP
❶ LOCATE PRINTER
Open the transport case, remove printer, printer
power adapter and power cord.
❷ CONNECT TO POWER
ADAPTER
Connect the power cord to the power adapter.
4
CONNECT TO POLLPAD
Plug the charging connector into the side
of the poll pad.
Remove poll pad charger.
❸ CONNECT TO PRINTER
Plug
with
the connector into the back of the printer
arrow on the cable facing down.
5
CONNECT TO PRINTER
connector into the back of the
the flat side facing down.
Plug the
printer
with
Note: Ensure secure connection
