Machine Tools OPERATING INSTRUCTIONS
13
4.4 Spindle and its balancing structure
Adjust the balance of spindle:Unti-clockwise loosen the screw 1, which can increase the
balancing power. Otherwise, reducethe balancing power。
4.5 Head clamping structure
Adjust the head clamping power. Loosen the nut 1 and remove the part 2,
which can adjust the power of head clamping. Generally speaking, put the
300N on the hand wheel, the head can’t shake.
