Machine Tools OPERATING INSTRUCTIONS
19
No. Symbol Qty
Specification and
model
Name Remarks
1 M1 1 1.5KW，Y900L1-4，B5
three phase
motor
2 M2 1 550W，Y8014，B5
three phase
motor
3 M3 1 90W，OB-25
Cooling pump
motor
With pump
4
QF1,QF2.QF
3
3 DZ47-63、IP、1A breaker
5 TC 1 JBK2-100( )/110,24,6V
Control
transformer
( )depend
on rating
voltage
6 KM1-KM4 4 3TB4022，110V，50-60Hz contactor
7 FR 1
JRS1-09/F、
2.5-4Awhole3.75A
Heat relay
8 SQ2,SQ2 2 LX5-11N Micro-switch
9 SQ1 1 JWL1-11 Micro-switch
10 QF 1 DZ5-20/330FH
Air automatic
switch
11 SA 1 HZ5-10/1,7LO2
Combination
switch
12 SB1 1 LAY3-01ZS/1red Control button
13 SB2,SB3 2 LAY3-11D/2green Control button
14 SB5,SB6 2 LAY3-11P/6black Indicator light
15 SB4 1 LAY3-01P/1 red Indicator light
16 HL 1 XD，faucet 6V Switch of door
17 EL 1 40W,24V bulb
18 1 JC-25 head of light light
