KNX GIRA Operating Instructions

Presence detector Mini
Button Function
Ó, Ô Function block 1: Extend minimum run-on-time
(10 seconds) individually
Set-up buttons of IR remote control
Button Function
Ù Walking test – Check detection field
Ú Reset sensitivity, brightness threshold and
run-on-time to presetting. Press for at least 3
seconds
Operation with IR remote control
If enabled, function block 1 can be operated manually by remote control. In manual operation,
brightness and motion detection for function block 1 are switched off until automatic mode is re-
set.
￭ Switch on, e.g. light: Press the ¿ button.
￭ Switch off, e.g. light: Press the Á button.
￭ Set automatic mode: Press the À button.
Manually changing settings with IR remote control
If enabled, individual settings for function block 1 can be changed during operation using a re-
mote control.
Sensitivity:
￭ Increase sensitivity: Press ´ button.
￭ Decrease sensitivity: Press ² button.
￭ Recall set sensitivity again: Press ³ button.
The manual adjustment of sensitivity by the sensitivity switch (7) is overwritten by the IR-
remote control and vice versa.
Brightness threshold:
￭ Change brightness threshold: Depending on requirement, press Ê button, Ë button, Ì
button or Í button.
￭ Set current brightness as brightness threshold: Press É button.
Run-on-time: The preset run-on-time of 10 seconds can be extended individually.
￭ Extend run-on-time: Depending on requirement, press ¼ button, Ï button,
Ð button, Ñ button or Ò button. Other values can be set with the
Ó/Ô buttons.
4 / 13
32589822 10867613 25.02.2020

KNX GIRA Specifications

General

Protection Class	IP20
Ambient Temperature	-5 °C to +45 °C
Communication Protocol	KNX
Mounting	DIN Rail
Number of Channels	Depends on model
