Kobalt 0054849 User Manual

OPTIONAL K-RAIL MOUNTING INSTRUCTIONS
1
1. Ensure wall studs are plumb and
square. Place the
K-Rail
®
(Item
#0103683, sold
separately) on the wall
studs at the desired location, with the
center of the
K-Rail
®
a minimum of
61-3/4 in. from the floor. Level the
K-Rail
®
and mark the location. K-Rail
®
must be attached to a minimum of 3
wall studs. Attach the K-Rail
®
to the
wall studs at the marked locations
using two wood screws (not provided)
per stud.
Measure 51-1/2 in. down from the
center of the top
K-Rail
®
. Install the
second
K-Rail
®
so the center of the rail
is 51-1/2 in. below the center of the top
K-Rail
®
.
Minimum
61-3/4 in. from
the floor
51-1/2 in.
center to center
2
2. Lift the cabinet and insert the top
outside cabinet brackets into the
K-Rail
®
on the top.
Note: 2 K-Rails
®
must be purchased.
10
Lowes.com
