TROUBLESHOOTING
LIFETIME HASSLE-FREE GUARANTEE
REPLACEMENT PARTS LIST
For replacement parts, call custom service at 1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Screw(s) will not
align into hole(s).
1. Natual properties of sheet
metal cause slight changes in
pre-drilled hole location.
1. Unit is not level. 1. Remove the unit from the wall
and ensure the studs are plumb
and square.
1. Place screws into all aligned holes
and hand tighten. Push a 3/8 in.
hole-punch through both holes to
force the alignment. With the
hole-punch in place, tighten all other
screws. When the hole-punch is
removed, the screw(s) should easily
fit into the remaining hole(s).
Doors will not
remain closed.
PART PART #
A
B
C
D
E
F
G
H
I
J
K
L
M
Top back panel
Left side
Right side
Top
Base
Bottom shelf
Shelf
Left door
Right door
Leg leveler assembly
Top middle back panel
Bottom middle back panel
Bottom back panel
19818B-A
19818B-B
19818B-C
19818B-D
19818B-E
19818B-F
19818B-G
19818B-H
19818B-I
19818B-J
19818B-K
19818B-L
19818B-M
19818B-N
19818B-O
19818B-P
19818B-AA
19818B-BB
19818B-CC
19818B-DD
19818B-EE
19818B-FF
19818B-GG
19818B-HH
19818B-II
19818B-JJ
DESCRIPTION PART
N
O
P
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
Door magnet
Door L shape pivot pin
Spring
ST4.8 x 10 mm screw
#8-32 x 3/8 in. bolt
#8-32 Nut
ST4 x 20 mm screw
Wall strap
Lock
Key
ST4.8 x 100 mm Pan head screws
5 x 15 x 1.2 mm Washer
Electrical bushing
DESCRIPTION PART #
This product carries a lifetime warranty. If the product is found to be defective, please call
1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday, or return the item to the place of
purchase with a copy of the original sales receipt. The distributor will, at its option, repair or replace
the product. This warranty gives you specific legal rights, and you may have other rights that vary
from state to state.
12
Lowes.com
Printed in China
