L
K
ASSEMBLY INSTRUCTIONS
10
Hardware Used
AA
x 4ST4.8 x 10 mm
Screw
Hardware Used
AA
x 2ST4.8 x 10 mm
Screw
9.
Slide and tighten the preassembled
screws in the top (D) to the assembled
unit. Tighten ST4.8 x 10 mm screws
(AA) to the front edge of top (D) to
connect the left side (B) and right side
(C) to top (D).
10.
Slide preassembled screws on the
drawer front (K) to the key slots in the
drawer (L). Tighten the screws. Use
ST4.8 x 10 mm screws (AA) to connect
drawer front (K) and top drawer (L).
AA
9
Lowes.com
9
C
D
A
AA
B
B
D
D
C
