24
CARE AND MAINTENANCE
Replacing the guide bar and chain (contd.)
• Remove the battery from the chain saw.
• Remove the supplied wrench (O) from the rear handle.
• Remove the two chain cover lock nuts (K) from the
chain cover by rotating them counterclockwise with the
wrench (O).
• Remove the chain cover from the mounting surface.
• The bar and chain can now be removed by lifting it
away from the main body of the saw and releasing the
chain from the sprocket.
• Remove the old chain from the bar.
Chain
Sprocket Bar
O
K
