Kobalt KHB 4124B-03 User Manual

9
ASSEMBLY INSTRUCTIONS
2. To Install/Remove Battery Pack
To Attach Battery Pack
a. Make sure that the variable-speed trigger
switch (C) is in OFF position and the trigger-
lock lever (B) is in the OFF position.
b. Align the raised portion on the battery pack
(not included) with the grooves on the bottom
of the tool, then slide the battery pack onto the
tool as shown.
c. Ensure that the battery-release buttons on the
battery pack snap into place and the battery
pack is secured to the tool before beginning
operation.
NOTICE: When placing the battery pack on the
tool, be sure that the raised rib on the battery pack aligns with the groove on the tool and the
latches snap into place properly. Improper assembly of the battery pack can cause damage to
internal components.
To Detach Battery Pack
a. Make sure that the variable-speed trigger switch (C) is in OFF position and the trigger lock
(B) is in the OFF position.
b. Press the battery-release buttons to release the battery pack.
c. Pull upward on the battery pack to remove it from the tool.
WARNING
• Battery tools are always in operating condition. Therefore, the trigger lock should always in
OFF position when the tool is not in use or when carrying the tool at your side.
2
B C
Battery-release
button

Kobalt KHB 4124B-03 Specifications

General

Brand	Kobalt
Model	KHB 4124B-03
Category	Blower
Language	English
