PACKAGE CONTENTS
HARDWARE CONTENTS
A Left Work Support 1
B Wheels 2
C
D
Mounting Brackets 2
E
Miter Saw Stand 1
F
Right Work Support
Handle
1
G
1
5mm Hex Key 1
PART DESCRIPTION QUANTITY
Hardware for handle
Hardware for wheels Miter saw mounting
hardware
Bolt M8 x 90mm
Qty. 2
Wheel Sleeve
Qty. 2
Spring
Washer 6
Qty. 4
Flat Washer 6
Qty. 2
Flat Washer 6
Qty. 4
Hexagon Bolt
M6 x 30mm
Qty. 2
Washer 14
Qty. 2
Big Flat
Washer 8
Qty. 2
Washer 10
Qty. 2
Locking Nut M8
Qty. 2
Hexagon Bolt
M6 x 55mm
Qty. 4
II
JJ
CC JJ AA DD EE
GG
FF
HH
BB
A
B
C
E
F
D
G
