2
1
kobalttools.com
7
I
J
2. Repeat with the remaining three legs. Lift the stand
and place it in an upright position.
Note: Check to ensure the stand is stable and all the legs
have the locking pins (I) engaged.
TO SECURE/LEVEL THE STAND
With the stand open and resting on a flat and level surface,
the stand should not move or rock from side to side. If
the stand rocks from side to side, the adjustable foot (J)
needs adjusting until the stand is balanced.
1. Lift the stand slightly so that you may turn the adjustable
foot (J) until the stand no longer rocks.
2. Turning clockwise will lower the foot.
3. Turning counterclockwise will raise the foot.
1
1
ASSEMBLY INSTRUCTIONS
