ASSEMBLY INSTRUCTIONS
8
A
I
Garden Hose Adapter Installation
8. Remove plastic shipping cover on water inlet on
front right side of power washer unit (A). Install
quick connect lter (I) to water inlet by hand,
tightening clockwise.
9. Slide the garden hose adapter (H) onto the
quick connect lter (I). It will "click" into place.
9
I
H
10. Attach a garden hose to garden hose
adapter (H). The water is now connected to
your power washer. Turn on water.
Note: To remove water hose, pull back on blue
collar and it will slide off the clear quick connect
lter. This can be done at any time. Water will
not come out of the garden hose as the blue/
black collar has a water stop check valve. Water
will only ow from the garden hose when it is
connected to the clear quick connect lter.
You have now completed the assembly and are
ready to begin using your electric power washer.
Read and observe all safety instructions.
