4
PACKAGE CONTENTS
PART DESCRIPTION PART DESCRIPTION
A Safety Button L Housing
B Bail Switch (Switch Lever) M Wheels
C Handlebar N Battery-Compartment Cover
D Auger-Speed Control Lever P Drive-Belt Cover
E Handlebar assembly Q LED Switch Button
F Chute-Rotation Handle R Rubber Paddles
G Rear Frame S Scraper Bar
H Handlebar Assembly Lock Knobs T Steel Auger Shaft
I
Storage Clip for Chute-Rotation
Handle
U LED Headlights
J Chute-Deector Handle V Deck
K Chute
Safety Button
The safety button must be pressed down before the motor can be started.
Bail Switch
The bail switch is located close to the handlebar of the snow blower. The switch engages and
disengages the motor and auger.
WARNING
The bail switch and the safety button are safety devices. Never attempt to bypass their
operations. Failure to heed this warning could result in serious injury.
Handlebar Assembly Lock Knobs
Lock and unlock the side rails of the handlebar in working or storage positions.
Auger-Speed Control Lever
Adjusts the auger speed which determines the throwing distance.
Chute-Rotation Handle
Rotates the chute to direct the discharged snow in the horizontal plane as desired. The handle
allows the chute to rotate from 100° left to 100° right.
Chute-Deector Handle
Adjusts the incline angle of the chute deector and the height of the discharge stream.
