11
PREPARATION
Breaking in the pump
Overload protector
• Check and tighten all bolts, ttings, etc.
• Turn the pressure regulator knob (D) fully
clockwise to open the air ow.
• Place the ON/OFF switch (C) in the OFF (O)
position (see Fig. 3) and plug in the power cord.
• Open the drain valve (H) completely (see Fig. 4).
• Turn the compressed air ON ( l ) (see Fig. 3) and
run the air compressor for 10 minutes to break in
pump parts.
• Place the ON/OFF switch (C) in the OFF (O)
position.
• Close the drain valve (H) (see Fig. 4).
This air compressor is equipped with a thermal
overload device which will turn the air compressor
off automatically if the air compressor becomes
overheated. If the motor turns OFF repeatedly,
check for the following possible causes rst: low
voltage from the outlet; lack of proper ventilation or
outside air; room temperature is too high; extension
cord is too long or wrong gauge wire used.
To reset the air compressor:
• Turn the air compressor off.
• Unplug the air compressor and allow it to cool for
30 minutes.
• Plug the air compressor into an approved outlet.
• Turn the air compressor on.
2
4
H
D
C
Close
Open
3
