Kobalt LK20175 - Page 21

21
Printed in China
PART DESCRIPTION PART #
1 AIR TANK 9413544210
2 DRAINING VALVE 9047091
3 HANDLE GRIP 9069190
4 WHEEL 9042100
5 WHEEL PIN 9011073
6 NUT M10 9122362
7 WHEEL CAP 9069199
8 FOOT 9038077
9 BOLT M8X40 9412531
10 WASHER 8X28X2 9414839
11 WASHER D8 9134372
12 NUT M8 9122452
13 HULL 9069186
14 PRESSURE SWITCH 9063294
15 ROCKER SWITCH 9414765
16 POWER CORD WITH
PLUG
9065838
17 LOCK CABLE 9064830
18 SCREW 3.9X16 9142773
19 SCREW 4X12 9114072
20 WASHER M4 9134403
21 WASHER D4 4100795
22 PRESSURE
REDUCER
9051246
23 SAFETY VALVE 9049516
24 QUICK COUPLING 9047086
25 GAUGE 1-1/2"
- REDUCED
PRESSURE
9052239
26 GAUGE 1-1/2" - TANK
PRESSURE
9052240
27 PLUG 9050613
PART DESCRIPTION PART #
28 ELBOW 9053583
29 RILSAN PIPE 9270026
30 PUMP B700060
31 MOTOR STACK
PROTECTOR
9069181
32 SCREW 3.9X13 9142591
33 AIR FILTER B780100
34 DELIVERY PIPE 9043794
35 ELBOW 9053159
36 CHECK VALVE 9048101
37 SHROUD 9069187
38 PLATE KOBALT
LOGO
9069188
39 SCREW TC 5X23 9114286
40 BULKHEAD 9069189
41 PLUG 9038003
42 WIRE JUMPER
(WHITE)
9064908
43 WIRE JUMPER
(GREEN)
9415375
44 SCREW TCEI M6X20 9101244
45 WASHER 6X14X1.5 9131687
46 PLUG FOR
DRAINING VALVE
9038905
47 SCREW 5X16 9143807
48 BUSCHING 9050728
49 SPACER 9050729
50 SCREW TCEI
M6X120
9411194
51 WASHER 6X12X1.5 9131654
52 SPRING WASHER D6 9411121
f Descriptions are provided for reference only.
REPLACEMENT PARTS LIST
