Assembling the lower brace support
(Fig. 6) - BAG U
● Attach the lower brace support (T) to the left
and right outer tubes using two hex bolts (ii),
as shown.
● Tighten the hex bolts (ii) with the adjustable
wrench (not included).
INSTALLING THE WATER TRAY TO STAND
(FIG. 7) - BAG X
● Place the water tray (B) on the stand. Align
the four holes in the water tray (B) with the
holes in the stand handles.
● Secure the water tray (B) to the stand using
four hitch pins (ss).
● Insert the pin from the outside and then
lock in place by inserting the end of the pin
into the hook on the hitch pin, as shown in
drawing.
ii
T
ii
7
ss
ss
B
P
FRONT
OF SAW
