12
OPERATING INSTRUCTIONS
REMOVE SANDING PAD
E
NOTE The tool features an air regulating
knob (E). The tool speed can be adjusted by
turning the air regulator knob (E) either
clockwise or counterclockwise. The maximum
tool speed can be obtained when the
concave line on the knob (E) is pointing
horizontally (See Figure 2).
When first making contact with the surface
you intend to sand, ensure the speed is set to
the lowest setting. Gradually increase the
power/speed as needed for your particular
sanding application instead of using too
much power/speed from the start.
2
NOTE If the sanding pad will not come loose,
1. Push in on the spindle lock button (D) and
rotate the spindle until you hear the
spindle lock into position. Loosen and
remove the sanding pad (B) by spinning
the pad in a counterclockwise direction.
there are 2 holes on either side of the spindle
lock button (See Figure 2).
D
2
1
D
C
B
PUSH
To Next Page
