INSTALLATION INSTRUCTIONS
1. Inspect the source
wiring before
continuing with
installation. Confi rm
voltage with volt
meter line-to-ground
(see Figure 1).
Volt meter should
read 120 Volts.
Confi rm voltage with
volt meter line-to-line
Volt meter should
read 230 / 240 Volts
(see Figure 2).
1
Volt Meter -
120 Volts
Ground Wire
Line Wire
Line Wire
2
Volt Meter -
230 / 240 Volts
Ground Wire
Line Wire
Line Wire
