INSTALLATION INSTRUCTIONS
12
3. Familiarize yourself with the pressure switch once cover is removed.
2. Remove the pressure switch cover by loosening the
screw (see Figure 3). Use a Phillips screwdriver (not
included). Pressure switch styles may vary.
WARNING
Risk of Shock. All wiring and
electrical connections must be
performed by a qualifi ed electrician
familiar with industrial motor
controls. Installations must be in
accordance with local and national
codes.
3
Screw
4
ASME Safety
Valve
Motor Power
Cord
Line
Terminal
Ground
Screw
Motor Cord Strain
Relief
Motor Terminal
Tank Pressure
Gauge
