ï¼»2. MACHINE FAMILIARIZATIONï¼½
2.3 MONITOR
2.3.1 NORMAL SCREEN
According to the types of the exhaust gas cleaning devices, the display of portion C is changed.
This manual explains operations based on the screens of the DPF and the SCR.
FLOW RATE
0064
L/min
E
F
E
F
E
F
E
F
E
F
A
B
D
E
6
C
127 8 9 10 11
1
2
4
4
3
DPF
SCR
DPF + SCR
1
5
2
3
1
5
2
3
Symbol Display
A Notification icons/clock
B
The images captured by the rearview camera and the side cameras are displayed.
C Meter
1
Hydraulic oil temperature meter
2 Fuel level meter
3
Engine coolant temperature meter
4
Soot deposition meter
5
DEF/AdBlue level gauge
D Switch
6
Setting menu
7
Switch setting
8
Travel speed selection
9 Work mode selection
10 Attachment mode selection
11 Auto acceleration ON/OFF selection
12
Range of option display
E
Set flow rate of front attachment
The flow rate at a light load work becomes a set value and is displayed.
Copyright©2020 Kobelco Construction Machinery Co.,Ltd. All rights reserved. [S2YY00041ZE03] [0701CsCshWbYs]
